Effortless setup and configuration, user-friendly graphical interface, and straightforward programming language enable anyone to easily start up the motion system with TITAN servo motor controllers.

Simple

TITAN Servo Motor Controllers are able to control most of the commonly used motors in the automation industry

Universal

TITAN Servo Motor Controllers come with 2ndSight Edge Intelligence that enables learning, analyzing, and monitoring of the motion system’s state and performance.

Intelligent
TITAN-SVX-ETH
Image is not available
Image is not available
Universal Ethernet Servo Motor Controller
Main Ethernet Servo Motor Controller
Slider

TITAN-SVX-ETH

Universal Ethernet Servo Controller with Machine Learning and Analytics


Edge Analytics
in Motion
Edge Analytics
in Motion
Edge Analytics
in Motion
Edge Analytics
in Motion
Edge Analytics
in Motion
previous arrownext arrow
Slider

Features

TITAN Ethernet Servo Motor Controller is a new generation of universal servo controller with advanced servo technology to drive most types of servo motors.



TITAN Ethernet Servo Motor Controller



•  Supports most types of servo motors: Stepper, Brushless Servo, Linear, Shaft, DC, and Voice Coil



•  Supports most commonly used communications: Ethernet, USB, and RS485



•  Comes with many advanced motion control features: Auto Parameter Detection, Auto Tuning, Force/Torque control, and Multi-thread Motion Programming



•  Uses the intuitive and easy-to-use TITAN Software that enables anyone to startup the servo motion system within minutes



•  Meets the new challenges and requirements in the emerging field of Industry 4.0/Industrial IoT with 2ndSight motion edge analytics algorithms and the new Arcus Servo 5.0 standard

Etherenet_02
RS485_02
USB_02
Ethernet Controller USB RS485

Motion

  • Configurable as Controller Mode or Pulse Mode
  • Motor Types Supported: 2Ph Stepper, 3Ph BLDC Rotary, 3Ph Linear, Voice Coil
  • Easy to use Auto Motor Parameter Detection Wizard and Auto Mechanical Parameter Detection Tuning Wizard
  • Motor and System Database File System Support
  • Open Loop Hold and Dynamic Gain
  • Advanced Plotting and Probing
  • Simplified Gain Setting
  • Force / Torque Control

Communication

  • USB 2.0 using Virtual Serial Comport
  • RS485 with 115K Baud
  • Ethernet 100M
  • Protocols Supported: Arcus ASCII, MODBUS RTU, MODBUS ASCII

IO

  • 8 Opto-isolated Digital Inputs
    -Controller Mode – Limit+, Limit-, Home, 5 General Inputs

    -Pulse Mode – Pulse, Dir, Enable, Clear, Reset, 3 General Inputs

  • 3 Opto-isolated Digital Outputs
    -Controller Mode – 3 General Outputs

    -Pulse Mode – In-pos, Alarm, 1 General Output

  • 1 Analog Input 0-5V range

Power/Size

Power

  • Voltage Input Range: 24VDC to 48VDC
  • Motor Peak Current: 8A

Size

  • 115 x 29 x 17.4 mm
Click here for Dimension & Pin-out

Max Ratings

  • Digital Input Forward Diode Max Current: -25mA
  • Digital Output Collector Max Voltage: +24V
  • Digital Output Sink Max Current: -45mA
  • Operating Temperature: -20 to 80˚C
  • Storage Temperature: -55 to 150˚C

Downloads

Download
TITAN-SVX Installation 4.07.exe 13.2MB exe
Hardware Manual 461KB PDF
Communication Manual 434KB PDF
Operation Manual 231MB PDF
PDF Spec Sheet 8.49MB PDF

SPECIFICATIONS

Features

TITAN Ethernet Servo Motor Controller is a new generation of universal servo controller with advanced servo technology to drive most types of servo motors.

TITAN Ethernet Servo Motor Controller

•  Supports most types of servo motors: Stepper, Brushless Servo, Linear, Shaft, DC, and Voice Coil

•  Supports most commonly used communications: Ethernet, USB, and RS485

•  Comes with many advanced motion control features: Auto Parameter Detection, Auto Tuning, Force/Torque control, and Multi-thread Motion Programming

•  Uses the intuitive and easy-to-use TITAN Software that enables anyone to startup the servo motion system within minutes

•  Meets the new challenges and requirements in the emerging field of Industry 4.0/Industrial IoT with 2ndSight motion edge analytics algorithms and the new Arcus Servo 5.0 standard

Motion

  • Configurable as Controller Mode or Pulse Mode

  • Motor Types Supported: 2Ph Stepper, 3Ph BLDC Rotary, 3Ph Linear, Voice Coil

  • Easy to use Auto Motor Parameter Detection Wizard and Auto Mechanical Parameter Detection Tuning Wizard

  • Motor and System Database File System Support

  • Open Loop Hold and Dynamic Gain

  • Advanced Plotting and Probing

  • Simplified Gain Setting

  • Force / Torque Control
Com

  • USB 2.0 using Virtual Serial Comport

  • RS485 with 115K Baud

  • Ethernet 100M

  • Protocols Supported: Arcus ASCII, MODBUS RTU, MODBUS ASCII
IO

  • 8 Opto-isolated Digital Inputs

-Controller Mode – Limit+, Limit-, Home, 5 General Inputs

-Pulse Mode – Pulse, Dir, Enable, Clear, Reset, 3 General Inputs

  • 3 Opto-isolated Digital Outputs

-Controller Mode – 3 General Outputs

-Pulse Mode – In-pos, Alarm, 1 General Output

  • 1 Analog Input 0-5V range
Power/Size

Power

  • Voltage Input Range: 24VDC to 48VDC

  • Motor Peak Current: 8A

Size

  • 115 x 29 x 17.4 mm
Downloads
Download
TITAN-SVX Installation 4.07.exe 13.2MB exe
Hardware Manual 461KB PDF
Communication Manual 434KB PDF
Operation Manual 231MB PDF
PDF Spec Sheet 8.49MB PDF
